KAMA 3m3 small toilet dredge truck Specification:
Top configuration: tank volume 3m3, WISCO Q345 automatic welding, wall thickness 5mm, head 6mm, standard SK-6 water ring vacuum pump, optional 5 tons oil pump, large suction power, long suction range, self-priming and self-discharging.
Standard anti-overflow valve, fecal window, 1 spout at the rear of the tank, hand-washing device beside the tank, 360°rotating boom on the top of the tank, and 1 8 meter fecal suction tube.
Optional configuration: optional float level controller, optional full electronic alarm, optional full automatic stop.
|
Technical Parameters of KAMA 3m3 small toilet dredge truck |
|||
|
Tank volume |
3m3 |
Tank thickness |
4-6mm |
|
Tank Material |
Carbon Steel |
Suction Distance |
≥6metre |
|
Suction Rate |
5min |
Emission Method |
Pressure or Gravity |
|
G.V.W |
4495kg |
Curb Weight |
2805kg |
|
Rated Weight |
1495kg |
Emission Method |
Pressure or Gravity |
|
Overall Dimension(mm) |
5330x1980x2200 |
Tank Dimension(mm) |
2600x1250x900 |
|
Technical Parameters of Chassis |
|||
|
Chassis Brand |
Kama |
Wheelbase |
2800mm |
|
Chassis Model |
KMC1041A28D5 |
Tyre Specification |
6.50-16LT 10PR |
|
Engine Horsepower |
Weichai 82 |
Gearbox |
5 speed forward, 1 revserse |
|
Axle Number |
2 |
Front/Rear Bridge |
1.6/3.0ton |
|
Fuel Type |
Diesel |
Emission Standard |
euro 6 |
|
ABS |
Standard |
Rear brake |
Drum |
|
Front Brake |
Disc |
Brake System |
Air Brake |
|
Top Speed |
95Km/h |
Steer power |
with |
Fecal suction truck Working parameter
| Extraction efficiency | Single full pumping≤5min | Sewage efficiency | After a single row is ≤4min |
| Horizontal suction | 40-60 meters | Vertical suction | ≤8m |
| Control method | Electric control + manual control | Operating position | Cab + front of tank |
Septic tank truck Working parameter New craft：
Optional configuration
Toilet suction truck Detailed image
