ISUZU 3 ton Towing wrecker truck
ISUZU 3 ton Towing wrecker truck Chassis configuration：
Adopt Qingling Isuzu chassis, single-row cab can be turned forward, Isuzu 98 horsepower engine, 5-speed gearbox, wheelbase 3360mm, 7.00 original steel wire tires, with direction boost, clutch booster, oil brake, original warm and cold air conditioning.
ISUZU 3 ton Towing wrecker truck Bodywork configuration：
3-ton conjoined bodywork, equipped with 4-ton hydraulic winch, imported hydraulic system, double-sided linkage operation, 25-meter steel wire rope, one set of tools, 4 straps, 3 rear working lights, 1 auxiliary light assembly 1 set of trachea assembly with 1 yellow long row of police lights.
ISUZU 3 ton Towing wrecker truck specification:
| General Technical Parameters | |||
| Overall Dimension | 5415x2030x2500 (mm) | ||
| Gross Vehicle Weight | 4500kg | ||
| Curb Weight | 4000kg | ||
| Chassis Specification | |||
| Chassis Parameters | Chassis Brand | ISUZU | |
| Cabin | Row and half, left Hand Driving | ||
| Engine | Model | 4JB1CN, 4 Cylinders | |
| Power | 72KW/98HP | ||
| Emission Standard | EURO V | ||
| Displacement | 2771mL | ||
| Fuel Type | Diesel | ||
| Gearbox | 5 Forward & 1 Reverse Gear | ||
| Front and Rear Axle Load | 2.5T/4.8T | ||
| Wheel Base | 3360(mm) | ||
| Overhang( Front/Rear) | 1015/2450(mm) | ||
| Angle(Approach/departure) | 24/9(°) | ||
| Brake System | Air Brake | ||
| Steering Gear | Power Assistant | ||
| Tire | 7.00R16, 6 Pieces with 1 Spare Tire | ||
| Maximum Speed | 110(km/h) | ||
| Superstructure | |||
| Winch | Quantity | 1pc | |
| Winch Rating Pulling Capacity | 4000 (kg) | ||
| Length of Steel Cable | 21 (m) | ||
| Remarks | 1. Equiped with One Set of Auxiliary Wheels 2. Fork 1 set 3. Yellow Warning Lamp 1pc 4. Double Side Hydraulic Operation 5. Bangdage 4 sets 6. chain hook |
||
ISUZU 3 ton Towing wrecker truck Advantage:
The loading surface of the platform is formed by stamping die once. The endurance is strong and the shape is not deformed. The plate surface is smoother, the structure is more professional and the strength is higher. The hydraulic parts adopt internationally renowned brands, and the product quality is guaranteed.
It integrates multiple functions such as lifting, carrying, dragging, pulling and so on. The hydraulic oil pipe is made of galvanized steel, which has good pressure resistance, strong heat dissipation performance, beautiful and durable.
