HOWO 60ton 360 degrees Rotator Wrecker tow truck
HOWO 60ton 360 degrees Rotator Wrecker tow truck Chassis：
adopts Sinotruk Howo chassis, half-row cab, original air conditioner in cab, Howo 380 horsepower engine, 10-speed gearbox, wheelbase 1800 + 4600 + 1350mm, 12.00R20 original steel tire, original abs, air brake .
HOWO 60ton 360 degrees Rotator Wrecker tow truck Bodywork：
Shaanxi Automobile Delong front four rear eight heavy-duty wrecker, 20T MAN bipolar conjoined bodywork (can be installed with a reinforced configuration of 25 tons), two-section six-sided boom, three-section support arm, split carriage, imported Hydraulic system, double-sided linkage operation, a set of remote control operation device, the front bumper is equipped with counterweight, the trailer performance is more stable.
Equipped with two 10 tons hydraulic winches, 45 meters of steel wire rope, diameter 18mm, equipped with 4 sets of steel forks, a set of steel plate lugs, a set of U-shaped tire holding device, a set of tools on board, a set of auxiliary lights A set of auxiliary trachea assembly, with a long yellow LED warning lights.
HOWO 60ton 360 degrees Rotator Wrecker tow truck specification:
|
Vehicle technical parameters
|
|||
|
product name
|
3 axis Sinotruk HOWO 60 ton sliding rotator wrecker tow truck
|
Dimensions
|
13.96×2.5×3.27 meters
|
|
Total mass
|
41 tons
|
Curb quality
|
24.87 tons
|
|
Hoisting specification
|
30 tons
|
Tops
|
30 tons
|
|
Chassis technical parameters
|
|||
|
Chassis name
|
Heavy truck HOWO
|
Chassis model
|
ZZ1317N4667D1H
|
|
Number of axes
|
2
|
Number of tires
|
13 (including spare tire)
|
|
Wheelbase
|
1.8+4.6+1.35 meters
|
Tire specifications
|
12.00R20
|
|
Gearbox
|
10 speed shift
|
Rear axle
|
16 tons rear axle
|
|
Fuel type
|
Diesel
|
brake
|
Air brake
|
|
Emission Standards
|
GB17691-2005 country V, GB3847-2005
|
||
|
engine model
|
Engine manufacturer
|
Displacement (ml)
|
horsepower
|
|
D10.38-40
|
Heavy Truck Group
|
9726
|
380 horsepower
|
|
Top basic configuration
|
|||
|
The standard configuration
|
25 ton joint top, with winch 15 ton x 2 hydraulic winch, 45 m steel wire rope, 4 sets of steel forks, a set of trailer sets, a set of steel ear lifting forks, a set of tire protection devices, a set of vehicle tools, auxiliary lights A set of assemblies, a set of auxiliary air pipe assemblies, with a set of yellow long row engineering lights.
|
||
HOWO 60ton 360 degrees Rotator Wrecker tow truck Advantage:
The loading surface of the platform is formed by stamping die once. The endurance is strong and the shape is not deformed. The plate surface is smoother, the structure is more professional and the strength is higher. The hydraulic parts adopt internationally renowned brands, and the product quality is guaranteed.
It integrates multiple functions such as lifting, carrying, dragging, pulling and so on. The hydraulic oil pipe is made of galvanized steel, which has good pressure resistance, strong heat dissipation performance, beautiful and durable.
