Dongfeng 8 ton 20ft refrigerated truck
Dongfeng 8 ton 20ft refrigerated truck specification:
Condition | New condition/left hand drive/4×2 | ||
Chassis | Brand | Dongfeng | |
Curb weight(kg) | 4500 kg | ||
Wheelbase(mm) | 3800 mm | ||
Dimensions(mm) | 7010*2330*3200 mm | ||
Front/Rear axle loading(kg) | 2500/6000 kg | ||
Front/Rear overhang(mm) | 1120/2355 mm | ||
Wheel track (front/rear) (mm) | 1685/1615 mm | ||
Approach/Departure angle(°) | 22/11 | ||
Max. driving speed(km/h) | 90 km/h | ||
Clutch | Reinforced diaphragm clutch | ||
Brake | Air brake | ||
Steering Gear | Power steering, hydraulic steering with power assistance | ||
Tire | Quantity | 6pcs with one spare tire | |
Specifications | 7.50R16 | ||
Transmission | Manual type, 6 Forwards and 1 reverse | ||
Cab | Single row seat, It can accommodate three people, with ABS | ||
Engine | Model | CY4SK251 | |
Fuel type | Diesel | ||
Displacement(ml) | 3856 ml | ||
Power(kw) | 115 kw | ||
Horsepower(HP) | 156 HP | ||
Cylinder number | 4 | ||
Emission standard | Euro 5 | ||
Upper | |||
Box | Size(mm) | 4800*2100*2100 mm | |
Volume(m3) | 20.0 CBM | ||
Max. Loading weight(tons) | 5tons-8tons | ||
Material | Roofing iron | ||
Rear hydraulic lifting system | Control model | Hydraulic control | |
Control panel | Close to the rear door | ||
Panel material | Carbon Steel | ||
Size(width * height) | 2100*1800mm | ||
Max. Loading capacity(kg) | 1500 kg | ||
Remarks |
|
Dongfeng 8 ton 20ft refrigerated truck Working parameter:
Insulation thickness | 80mm ester urethane | Inside and outside materials | 2.2mm FRP / Stainless steel plate | Unit brand | Domestic, imported / independent, non-independent |
Floor material | FRP / Aluminium skid plate / Stainless steel skid plate | Installation location | Front, skirt, top | Bottom ventilation slot | Optional, aluminum alloy profile |
Cooling time | 30 minutes | Thermal curtain | Optional | Control position | Cab |
Meat hook | Optional | Insulation effect | 24 hours temperature rise 5 degrees | External power supply | Optional |
Cooling temperature | Minus 20-5 degrees | Constant temperature unit | Optional | Temperature and humidity printer | Optional |
