Dongfeng 15 ton Asphalt gravel sealer truck
Dongfeng 15 ton Asphalt gravel sealer truck Adopt Dongfeng TianJin Cab, Cummins 190hp/210hp Euro 3 engine in the cloud, eight-speed gearbox, a wheelbase of 4500mm, tires 1000-20, and a vehicle size of 9300×2450×3200mm.
Our asphalt distributor truck for sale features and advantage
1.) Automatic asphalt distributor boasts three layers. It can adjust the spray amount according to its operational speed.
2.) The whole asphalt spraying process can be finished in the cab.
3.) Each nozzle is controlled by separate computer. The spray width can be adjusted at random.
4.) The control procedure is equipped with two control systems, cab and post operational platform to ensure the reliability of asphalt spray.
5.)The computer control system adopts modular design for lower accident rate and maintenance.
6.)The temperature of asphalt in tank is kept below or equal to two degrees per hour
7.)The distributor is equipped with automatic blowing device to shift the asphalt outside to the tank
specification:
|
Dongfeng 15 ton Asphalt gravel sealer truck Mass parameter:
|
|||||||
|
Kerb Weight(kg)
|
9300
|
Total Weight(kg)
|
16000
|
||||
|
Rated loading Weight(kg)
|
6570
|
Dimension(mm)
|
9300×2450
×3200
|
||||
|
Chassis Parameter:
|
|||||||
|
Chassis Model
|
DFL1160BX
|
Tyre model
|
9.00-20
|
||||
|
Wheelbase (mm)
|
5000
|
Tread (mm)
|
1430/2568
|
||||
|
Front Overhang(mm)
|
1880
|
Rear Overhang(mm)
|
1800
|
||||
|
Approach angle,Departure angle
|
20°/14°
|
||||||
|
Engine parameter:
|
|||||||
|
Engine model
|
B190 33
|
Manufacturer
|
Dongfeng Cummins Engine Co., Ltd
|
||||
|
Max.Power(kw)
|
140
|
Max. Torque(N.m)
|
/
|
||||
|
Fuel
|
Diesel
|
Displacement(ml)
|
5900
|
||||
|
Chip sealer specification:
|
|||||||
|
Tank Capacity(m³)
|
3
|
Chippings Capacity(m³)
|
5
|
||||
|
Hydraulic pump model
|
CBQ-F550
|
Spray width
|
3100mm
|
||||
|
Hydraulic motoe
|
L2F63W2P2(LIYUAN)
|
Spray Value
|
0.5-3.0(Kg)
|
||||
|
Controller
|
ZM-3D
|
Insulation Thickness
|
50mm
|
||||
|
Generator(Converter)
|
YT6800E(YITENG)
|
Nozzles
|
26
|
||||
|
Asphalt pump
|
QGB450(SHANGGUI)
|
Burner
|
G20(Riello)
|
||||
