DFAC 8000 liter to 10000liters waste truck Product Description:
DFAC 8000 liter to 10000liters waste truck Chassis configuration: new half-row cab, thickened high-strength front bumper, front fog lights, wide-angle rearview mirror, front road mirror, Dongfeng 6-speed gearbox, Yuchai 130 hp, Cummins 170 hp, 190 hp Wheelbase 3950mm 4500mm, 9.00-20 1000-20 original nylon tires, 3.6 tons front axle, 9 tons rear axle, intercooled supercharged.
DFAC 8000 liter to 10000liters waste truck Model configuration: The effective volume of the car body is 8-10 cubic meters. The loading cycle of the car is one-key operation. It is equipped with 9 hydraulic cylinder brakes and no auxiliary pressure plate. The hydraulic system can be controlled electrically or manually. Rear flip mechanism, can choose to hang plastic bucket, iron bucket, or bucket type. Sewage collection box at the bottom of the filler, the sewage in the car box can flow into it, and can be discharged through the ball valve when unloading garbage.
DFAC 8000 liter to 10000liters waste truck Specifications:
Dongfeng 8cbm-10cbm Swept-body Refuse collector Self-discharging Swing Arm Garbage Truck | |||
Product name | swing arm garbage truck | Product brand | Dongfeng |
Condition | new | Color | blue |
Overall size | 8100x2480x3300(mm) | capacity | 6-8 CBM |
total mass | 16000kgs | Curb quality | 6000kgs |
Cab | one and half cabin | ABS / air conditoner | optional |
Axle load | 1800/2695(kg) | Wheelbase | 4500(mm) |
Number of axes | 2 | Maximum speed | 90(km / h) |
Number of springs | 6/6+5 | Drive type | 4*2 LHD |
Number of tires | 6+1 | Tire specifications | 9.00R20 10.00R20 |
Brake | Air brake | Air conditioner | With |
Engine brand | CUMMINS | Engine horsepower | 170hp |
Fuel Type | Diesel | Emission Standard | EURO 3 |
DFAC 8000 liter to 10000liters waste truck structure diagram:
DFAC 8000 liter to 10000liters waste truck Structure diagram:
DFAC 8000 liter to 10000liters waste truck Detail drawing:
Customizable garbage truck models
