10 wheel faw 20ton to 25ton heavy duty tow truck
10 wheel faw 20ton to 25ton heavy duty tow truck Chassis：
Adopt Jiefang J6 series chassis, Changchun J6M flat roof cab, original cab air conditioner, Jiefang 285 horsepower engine, 10-speed gearbox, wheelbase 5800 + 1350mm, 10.00R20 original steel tire, air brake, original ABS.
10 wheel faw 20ton to 25ton heavy duty tow truck Bodywork：
10 tons of united bodywork, two-section six-sided boom, three-section support arm, split carriage, imported hydraulic system, double-sided linkage operation device, front bumper equipped with counterweights, both in performance and endurance are relatively strong.
Two 8-ton electro-hydraulic winches, 35m steel wire rope, 16mm in diameter, equipped with 4 sets of steel forks, one set of trailers, one set of steel plate lugs, one set of tire holding devices, one set of tools on board, auxiliary light assembly 1 set, 1 set of auxiliary trachea assembly, 1 yellow long row LED engineering warning light.
10 wheel faw 20ton to 25ton heavy duty tow truck specification:
| Vehicle technical parameters | |||
| product name | Wrecker | Dimensions | 10.62×2.5×3. 36 meters |
| Total quality | 25 tons | Curb quality | 18.72 tons |
| Winding specifications | 20 tons | Tops | 20 tons |
| Chassis technical parameters | |||
| Chassis name | Liberation J6 | Chassis model | CA5250JSQP63K1L5T1E5 |
| Number of axes | 3 | Number of tires | 11 |
| Wheelbase | 5.8 + 1.35 meters | Tire specifications | 10.00R20 |
| Gearbox | 10 files | Rear axle | 10 tons |
| Fuel type | Diesel | brake | Air brake |
| Emission standard | GB17691-2005 National V, GB3847-2005 | ||
| engine model | Engine manufacturer | Displacement (ml) | horsepower |
| CA6DK1-28E5 | China FAW | 7146 | 285 horsepower |
| Basic upload configuration | |||
| Standard configuration | 20-ton conjoined bodywork, equipped with winch 10 tons x 2 hydraulic winch, 45-meter steel wire rope, 4 sets of steel forks, one set of trailers, one set of steel plate lugs, one set of tire protection devices, one set of tools on board, auxiliary lights One set of assembly, one set of auxiliary trachea assembly, and one set of yellow long-row engineering warning lights. | ||
10 wheel faw 20ton to 25ton heavy duty tow truck Advantage:
The loading surface of the platform is formed by stamping die once. The endurance is strong and the shape is not deformed. The plate surface is smoother, the structure is more professional and the strength is higher. The hydraulic parts adopt internationally renowned brands, and the product quality is guaranteed.
It integrates multiple functions such as lifting, carrying, dragging, pulling and so on. The hydraulic oil pipe is made of galvanized steel, which has good pressure resistance, strong heat dissipation performance, beautiful and durable.
