[Technical parameters of the vehicle] |
|||||
|
product name |
CLW5162GJYJ4 fuel tank truck |
||||
|
Total mass (kg) |
15,600 |
Tank volume (m3) |
15 |
||
|
Rated mass (kg) |
8000 |
Dimensions (mm) |
8500, 8900X2500X3150 |
||
|
Curb weight (kg) |
7405 |
Cargo compartment size (mm) |
XX |
||
|
Rated passengers (person) |
Total mass of semi-trailer (kg) |
||||
|
The number of passengers in the cab (person) |
3 |
Maximum load of saddle (kg) |
|||
|
Approach angle/departure angle (°) |
17/12 |
Front suspension/rear suspension (mm) |
1530/2270,1530/2370 |
||
|
Axle load (kg) |
5600/10000 |
Maximum speed (km/h) |
76 |
||
|
Remarks: |
Remarks: Effective volume of tank: 15 cubic meters, medium: gasoline, item number: 3, density: 700 kg/cubic meter. Optional with chassis Cab. Overall length/wheelbase/rear suspension/tank size (long × long axis × short axis) (mm) one-to-one correspondence: 8500/4700/2 270/5600/2150/1480; 8900/5000/2370/6000/2100/141 5. Material of side and rear guards: Q235B, both side and rear guards are connected by bolts, the cross-sectional size of the rear guard (width×height) 60×100(mm), the rear protective ground clearance: 490mm. Install a driving recorder with satellite positioning function, install the front wheel Disc brakes, only use chassis radial tires, ABS controller model: 44600XXXX0, manufacturer: WABCO Automotive Control System (China) Co., Ltd. Refueling device model/manufacturer: CS20D1110F/Zhengxing Technology Co., Ltd., 80YH CB-60/Shandong Boshan Qilu Oil Pump Factory, YHCB-1000/5-A, YHCB-1000/5B, YHCB -300/3-BL/Yongjia Sanjiang Petroleum Machinery Factory. |
||||
|
【Chassis technical parameters】 |
|||||
|
Chassis model |
HFC1161P3K2A47F |
Chassis name |
Truck chassis |
||
|
Trade name |
JAC |
manufacturer |
Anhui Jianghuai Automobile Co., Ltd. |
||
|
Number of axes |
2 |
Number of tires |
6 |
||
|
Wheelbase (mm) |
4500, 4700, 5000, 5300, 5700, 5800, 4000 |
||||
|
Tire specifications |
9.00-20 16PR, 9.00R20 16PR, 10.00R20 16PR, 10R22.5 16PR |
||||
|
Number of leaf spring |
9/9+7,3/4+3,3/9+7 |
Front track (mm) |
1900, 1963, 1830, 2010, 2060 |
||
|
Fuel type |
Diesel oil |
Rear track (mm) |
1800, 1850 |
||
|
Emission standard |
GB17691-2005 National IV, GB3847-2005 |
||||
|
engine model |
Engine manufacturer |
engine capacity |
Engine power |
||
|
CA6DF4-20E4 YC6J200-42 CA6DF4-18E4 YC6J180-46 YC4E160-42 CA4DF4-17E4 CA4DLD-17E4R JND412D165-42 WP4.165E40 WP6.180E40 CA6DLD-18E4R |
FAW Jiefang Automobile Co., Ltd. Wuxi Diesel Engine Factory Guangxi Yuchai Machinery Co., Ltd. FAW Jiefang Automobile Co., Ltd. Wuxi Diesel Engine Factory Guangxi Yuchai Machinery Co., Ltd. Guangxi Yuchai Machinery Co., Ltd. FAW Jiefang Automobile Co., Ltd. Wuxi Diesel Engine Factory FAW Jiefang Automobile Co., Ltd. Wuxi Diesel Engine Factory Anhui Jianghuai Navistar Diesel Engine Co., Ltd. Weifang Weichai Deutz Diesel Engine Co., Ltd. Weifang Weichai Deutz Diesel Engine Co., Ltd. FAW Jiefang Automobile Co., Ltd. Wuxi Diesel Engine Factory |
6740 6500 6740 6494 4260 4750 4400 4748 4500 6750 6600 |
150 147 135 132 118 127 127 121 121 132 134 |
||
