Dongfeng 5m3 drinking water tanker truck

Dongfeng 5m3 drinking water tanker truck
Dongfeng 5m3 drinking water tanker truck

[Technical parameters of the vehicle]

product name

CL5071GSS3 drinking water tanker truck

Total mass (kg)

7495

Tank volume (m3)

5

Rated mass (kg)

3500

Dimensions (mm)

5995X2050X2450

Curb weight (kg)

3800

Cargo compartment size (mm)

XX

The number of passengers in the cab (person)

3

Maximum load of saddle (kg)

Approach angle/departure angle (°)

19/15

Front suspension/rear suspension (mm)

1115/1580

Axle load (kg)

2925/4570

Maximum speed (km/h)

95

Remarks:

Remarks: The effective volume of the tank: 5 cubic meters, the overall dimensions of the tank

(long × long axis × short axis) (mm): 3400 × 1600 × 1000.

【Chassis technical parameters】

Chassis model

EQ1070T35DJ3AC

Chassis name

Truck chassis

Trade name

Dongfeng

manufacturer

Dongfeng Motor

Co., Ltd.

Number of axes

2

Number of tires

6

Wheelbase (mm)

3300

Tire specifications

7.00R16,7.00-16

Number of leaf spring

8/9+5

Front track (mm)

1586

Fuel type

Diesel oil

Rear track (mm)

1530

Emission standard

GB3847-2005, GB17691-2005 National Ⅲ

engine model

Engine manufacturer

engine capacity

Engine power

YC4F115-30

YZ4DA3-30

CY4102-C3D

YCND27-115-30

CY4100-E3F

YN33CR

YN38PE-1

D28D10-3D3

D28D10-3D2

4D28TCI

Guangxi Yuchai Machinery Co., Ltd.

Weichai Power Yangzhou Diesel Engine Co., Ltd.

Dongfeng Chaoyang Chaochai Power Co., Ltd.

Guangxi Yuchai Machinery Co., Ltd.

Dongfeng Chaoyang Chaochai Power Co., Ltd.

Kunming Yunnei Power Co., Ltd.

Kunming Yunnei Power Co., Ltd.

Dongfeng Light Engine Co., Ltd.

Dongfeng Light Engine Co., Ltd.

Chang Chai Co., Ltd.

2659

3660

3856

2659

3707

3298

3760

2771

2771

2834

85

81

80

85

73

79

85

75

75

72
